‘Groundbreaking’ Passivhaus school project gathers pace

Image credit: Holmes Miller

WORK is progressing on a new classroom block on the grounds of Sciennes Primary, which will see it become the first Passivhaus primary school building in Edinburgh.

The extension will provide extra space for classrooms, with Sciennes described as already having one of the largest rolls in the country. The school has been using temporary accommodation to cope.

Features will include thermally broken foundations, quadruple glazing and air source heat pumps. A mechanical ventilation with heat recovery (MVHR) system will be installed to provide fresh filtered air directly into classrooms whilst mitigating ventilation heat losses by up to 90%.

The structure uses stone-clad, cross laminated timber (CLT) to help minimise heat loss and simplify the airtightness of the building’s envelope. It will also adopt building materials such as Foamglas within the load-bearing construction to mitigate thermal bridges at the foundations, doors and windows.

The new classrooms will be situated behind the current B-listed school building. The existing primary school building remains open during the build.

Outside of the classrooms there will be a rain garden and permeable landscaping to minimise the discharge of surface water into the combined sewer.

The structural engineering embodied carbon calculations have been provided by Edinburgh-based Will Rudd and led by Jamie Paterson. Jamie is one of only a handful of structural engineers who is also a certified Passivhaus designer in Scotland.

Maxi Construction was awarded the £2.7 million contract to design and build the new classroom block by Edinburgh City Council. The project is scheduled to be finished in summer of this year.

Jamie Paterson said, “It is so important that new buildings are designed to be ‘Net Zero ready’ to avoid the need for future upgrades, which can often be costly and imperfect. This new Passivhaus classroom block will provide an energy efficient building that will continue to improve as the national energy grid decarbonises.

“Adopting the Passivhaus standard in combination with embodied carbon conscious design is a huge step towards achieving the target of net zero by 2045. With quadruple glazing and state of the art heating and ventilation systems, this building will not just have a very low carbon footprint, it will also save significantly on energy costs for years to come.

“Maxi Construction has been doing a great job on site, evidenced by the recent interim air test of just 0.05 ACH. This figure is considerably better than required to meet the Passivhaus Standard and a great sign going into the next phase of construction works.

“As one of only a few structural engineers who is also a certified Passivhaus designer in Scotland, myself and Will Rudd are perfectly placed to assist in these sorts of builds. This is a first for Edinburgh, but it certainly won’t be the last.”

John Aitchison, Maxi Construction’s MD, added, “At Maxi Construction we appreciate the importance of protecting our built environment and are actively educating and developing our team to be at the forefront of this movement to net zero by 2045. We’re honoured to be continuing our working relationship with The City of Edinburgh Council on their first Passivhaus primary school building.  With such an educated team of designers behind us we’re enjoying our first experience of working to the Passivhaus standard.”
